QUESTIONS & ANSWERS

Ask a Question
  • i have a bobcat wc-8a wood chipper and what to use it on my case tv380

    Sorry, that attachment is a mess to deal with.  Here is a link to what a customer did.  You will end up stripping out all of the wiring and turning it into a mechanical chipper like regular chippers operate.  Please click the link.

    https://www.skidsteergenius.com/apps/help-center#!bobcat-chippers-explained

  • I’m trying to hook up a bobcat soil conditioner to my cat to my 299 I have your Skid-steer genius adapte 1-815-979-5844

    Did you follow these instructions.

    https://www.skidsteergenius.com/apps/help-center#!bobcat-soil-conditioners-explained

  • WE ARE LOOKING FOR AN AFTERMARKET SOLUTION FOR A BOBCAT WIRING HARNESS/ CONTROL MODULE/ BRACKET KIT. THE BOBCAT NUMBER FOR THIS 14 PIN CONNECTOR KIT IS 6733136.

    Are you asking if we make a similar harness?  Sorry, but we do not.

  • Hi, I recently purchased a GEHL RT 210 and a SUIHE Skid Steer Concrete Mixer. The concrete mixer has a solenoid to open and close the concrete door/chute. The RT 210 does not have an electrical pin connector as this is a GEHL option. I am looking for an option to connector the solenoid (which needs to be wired to a connector as well) to the GEHL RT 210 to be able to open and close the concrete door/chute. Can you please recommend something?

    OMG.  It's a Chinese invasion of concrete mixers.  I just checked the Richie Bros auction site and see them being dumped by the dozens.  Does your machine have a control harness on the boom?  Is it a 14 pin?  I guess I should create a kit for these because it is the same factory using the Suihe, Great Bear and Wolverine name dumping this equipment.

  • Good afternoon. I have an older Bobcat 68" angle broom with a 14 pin connector - I want to use it on a T595 Bobcat that only has the Bobcat 7 pin connector on the machine - do you have a simple fix for this like an adapter harness of some sort. Thanks

    Yes. It is called the SG-CB-4008.

  • Have Kubota SVL want to use a bobcat dozer blade with small round seven pin what adapter do i need

    That is all covered in our FAQ section which can be found here.

    https://www.skidsteergenius.com/apps/help-center#!bobcat-dozers-explained

  • HAVE A PR84B THAT HAS A 3 PIN CONNECTOR WANTING TO USE ON A KUBOTA SKIDSTEER. WILL THIS TYPE OF HARNESS WORK?

    You can buy this adaptor

    https://www.skidsteergenius.com/collections/adapters/products/sg-ct14-jd03-machine-side-cat-d-series-14-pin-to-attachment-side-john-deere-3-pin


    Or you can buy this connector and slide the sockets out carefully out of your existing 3 pin connector and use thm in the new connector bcause they are the same.  Here is the connector.

    https://www.skidsteergenius.com/collections/electrical-connectors/products/14-pin-female-kit-deutsch

    Rob

  • I purchased a 14 pin to 7 pin from yall late last yr it might have been through DFM. But i lost the diagram for it i think it a 4 function.. have yall come out with a 5 or 6 function?

    We have a 6 function that works on pilot controls and soem hand foot controls.

  • I have a John Deere PR72 power rake with what looks to be a 5 pin connector. Would like to use it on a new Cat 259D3 skid steer. Do you have a harness?

    It should be a 3 pin and this will work.

    https://www.skidsteergenius.com/collections/adapters/products/sg-ct14-jd03-machine-side-cat-d-series-14-pin-to-attachment-side-john-deere-3-pin

  • I purchased a CB-4014 from you last year. I went thru the programming procedure and it worked for my snow blower. I set it up again this year and I cannot get the LED to light up when I go thru the programming procedure. All fuses are good. Do you have any suggestions or procedures I can follow to get it working?

    Have a look at this troubleshooting video and let me know what you see.

    https://youtu.be/7566JZLRus0

  • I received your WiFi camera system and the manual says charge for 8 hours. It does not say if the unit has to be turned on or not and it does not describe the red blinking light, or what indicates charging or fully charged. The manual says to click on Video #130 for a detailed set up and operational video, but #130 does not exist on your website. Also not crazy about all the cords that need to be connected in order for the camera to be connected to the battery. This also requires that the pig-tail cord for charging is always exposed to the weather and I blow snow in Minnesota. Are these cables weather rated to withstand the cold wet snow?

    For your application, we do not think you will be happy with it.  This is a wireless spot camera used for blind areas in average conditions.  We developed a much hardier solution for your needs 15 years ago and sell them as such.  The hardier camera is used for fixed applications, has a larger view, heated camera, permanently sealed connections and no apps to connect to.  We are perfectly happy to have this unit returned and replace it with a fixed unit.
