SG-BC14-JD03 - Machine Side Bobcat 14 Pin to Attachment Side John Deere 3 Pin | Skid Steer Genius

  • $265.00

Ask a Question

Here's a Genius idea.  Why not allow people with John Deere 3 Pin controlled attachments run them on their Bobcat Skid Steer Loader?  This adapter does just that.  Just plug one end into your Bobcat 14 Pin Connection and plug the other into your attachment equipped with a 3 pin connector.  Turn on your machine and get to work.  This is another Genius product.  The best ideas at the best prices.



Also works with Cat-D Series, Kubota, Case, Gehl, Mustang, Takeuchi, New Holland 14 pin.

Note:  John Deere 3 Pin outputs only 2 switched ports.


We Also Recommend

QUESTIONS & ANSWERS

Ask a Question
  • Will this work on a 2021 Takeuchi TL12V2 high flow skid steer?

    Yes it will work if you have a machine with a 14 pin installed and a John Deere attachment with a 3 pin connector.

  • Mine has the 7 pin

    What you selected will not work.  It states that it is for a 14 pin to 3 pin.

    CLICK HERE FOR THE 7 PIN LINK

  • Will this work for the t76 bobcat

    Does your T76 have a 14 pin connector or a 7 pin?  This adapter is for older Bobcat's that have a 14 pin or newer ones where a 14 pin has been added.

  • I have this adapter to run a JD power rake on a Kubota skid steer, can you tell me what buttons to use on the Kubota to angle the JD rake ? Thanks for your help.

    It is fired by the C & D pins.  Every year and option of Kubota is different.  If you respond to this, I can send you the Kubota spec sheet.

  • Is this the adapter I need to go from a JD PR72B power rake to a Kubota skid steer? Thanks for your help

    How about this?

    CLICK HERE

  • Can I get the female three pin also with this.

    CLICK HERE

  • I have this adapter for a new holland c337 and a John Deere power rake. What button do I need to use on the loader to angle it?

    The left handle top buttons that trigger pins C & D.

  • Is this the adapter I need to attach a JDPR 84B power rake to my Cat 289D3 ?

    If the rake has the 3 pin JD connector, yes.  Sometimes there is a square connector farther down.

  • Will this connection fit a case tr340 to a John Deere Harley rake

    If the Harley rake has the small 3 pin connector it will work.

  • Needing to go from 3 pin Deere Attachment to 14 pin Cat machine. Cannot seem to find that exact match on the website unless I have just overlooked it. Thank you.

    This is the item.

    SG-BC14-JD03

    The first 4 pins are all common between most machines.  Cat just screws it up on the last two.

  • I'm looking for a Bobcat Machine side 14 pin to a John Deere Attachment side 14 pin. I don't see that option.

    It's very easy to find our items with our search feature.  In this case, you have a Bobcat machine BC going to a John Deere Machine JD.  The call out would be BC14-JD14.

    Here is the link.

    https://www.skidsteergenius.com/collections/adapters/products/sg-bc14-jd14-machine-side-bobcat-14-pin-to-attachment-side-john-deere-14-pin-skid-steer-genius

  • Will this harness work on a JCB Skidsteer on the 14pin?

    Yes it will fit on the 14 pin and then it needs to plug into an attachment from John Deere with a 3 pin connection.

  • Would this connector work with a Kubota SVL75-2 HFWC

    If you are connecting to a John Deere attachment.

  • would you be able to tell me which pin locations control the button 5 and 6 on a Caterpillar 262 D? I bought the Cat 14 pin to John Deere 3 pin connector, but some pins need to be moved around to correct locations

    This should be pinned out to B - Ground and C & D for controls which are the buttons next to your left leg on top of the stick.  There is a sticker on the glass showing you this.

  • I’m picking up a John Deere power rake I think it has a three pin connection I’m trying to hook it up to my bobcat skid steer’s how much is the adapter and how fast can I get it

    I believe that this is what you need.

    https://www.skidsteergenius.com/collections/7-pin-controllers/products/sg-cb-2000x-100-jd-genius-7-pin-controller-for-bobcat-loaders-john-deere-3-pin

  • I have a customer with a Deere CTL, PIN 1T0333DBPB0201978. He would like to run his Bobcat attachments with this machine. What adapter harnesses are necessary to make this happen? Is there one, or is there a combination of harnesses. Originally we ordered your harness SG-BPH-14-6-9DP as well as the Bobcat harness 6725353, but this doesn't seem to work.

    Your best to look at the harness selector. John Deere does not provide a powered K pin so Bobcat harnesses won't work. It's all part of their plan.

    https://www.skidsteergenius.com/pages/choose-your-harness-here

  • I have a Cat 279D skid steer with a JD Power rake. is this the adapter that I need?

    If the power rake has the small 3 pin plastic connector, then this would be the right one.
    ______________________________________________________

  • WOULD PART# SG-BC14-JD03, FIT ON A CASE TV380 SKIDSTEER WITH A 14 PIN HOOK UP, ANS A JD 3 PIN ATTACHMENT?

    Correct.

  • What about a jcb 14pin?

    JCB uses the same pin out as the original Bobcat 14 pin.  The only issue is that they option out the controls so you could be missing some buttons and your attachment may require 1,2,4 or six controls.  That is the toughest thing to judge.
